MFX 1601 - Masterfix заклепка полукруглая головка

MFX 1601 - Masterfix заклепка полукруглая головка

Материал:
Алюминий [AlMg3,5]
Сталь оцинкованная



Длинна (мм)

  ø d l
[+1/-0,2]
Ø dk k Ø dm p

N

N

16013210

3,2

[+0,35/-0]

Ø 3,4

10,0 Max. 6,0 6,0
[+/-0,24]
≤1,4 ~1,80 ≥27 930 525
3214 14,0 Max.10,0
16014008

4,0

[+0,35/-0]

Ø 4,3

8,0 Max. 4,0 8,0
[+/-0,29]
≤1,7 ~2,20 ≥27 1.140 885
4010 10,0 Max. 6,0
4012 12,0 Max. 8,0
4016 16,0 Max. 12,0
16014808

4,8

[+0,35/-0]

Ø 5,1

8,0 Max. 4,0 9,5
[+/-0,29]
≤2,0 ~2,65 ≥27 1.575 1.185
4810 10,0 Max. 6,0
4811 11,0 Max. 7,0
4812 12,0 Max. 8,0
4814 14,0 Max. 10,0
4816 16,0 Max. 12,0
4818 18,0 Max. 14,0
4820 20,0 Max. 16,0
4825 25,0 Max. 21,0
4830 30,0 Max. 26,0
